29TH OCTOBER 2023 BBKM1608 : CONTROL SYSTEM ENGINEERING

Category: Engineering | Admission Mode: Self Pace | Quota: 7/20 enrolled

Video | Duration: 2023-10-01 To 2025-05-30 | Course Fees: 0.00 MYR

Course Outcome(s)

CO1: Analyze and derive the mathematical model system in frequency domain and time domain.
CO2: Analyze the transient response, system stability and state response for first and second order systems.
CO3: Design the PD, PI, PID, Lag, Lead and Lag-Lead compensator using root locus technique and frequency response technique.
CO4: Evaluate the systems performance between compensated and uncompensated based on transient and steady-state response.

Description

This module will cover the analysis of the system’s stability and performance of the control system by using the time domain and frequency domain approaches. PID controller will be used to improve the transient and steady-state performances in the time domain approach. In the frequency domain approach, the bod plot method will be utilized. The lead, lag and led-lag compensators are introduced in improving the control system's performance using the frequency approach.
